Card name vs # in 1401/1406 & 729 Tape Drives vs # in Spares

Derived in part from

- 1401 Unit Plugging Sorted By SMS card type
- 729 Mod V, Plugging Sort by Card Type
- 729-SMS-Card-Usage-.jpg

Revision history
- April 9, 2009 - added card types and counts for 729 Mod 5
- June 24, 2009 - added 17 spares from "Weird Stuff", which collects and saves for Lyle Bickley to give to CHM volunteer restorers
       including 5 types we didn't have before
- Dec 10, 2009 - added info from 729-SMS-Card-Usage-.jpg
- Feb 27, 2011 - e-mail from Jim Hunt
- Jan 28, 2018 - e-mail from Jim Hunt, here, identifying cards obtained from the 729 Mod 1 backplane by Marc Verdiell
        The card types used in our equipment are (I assume) added to Spares, and are so counted below.
        Note: Spares of APF, APG, APH, AR, BJ, LZ, MD, MH, SB, YAW, YHM, ... are no longer ZERO, and are removed from that category.
        And there is now more than one spare for MD
None, Zero in spares 2JHX, 3JWX, 6J--, 6JXD, AAZU, AAZV, ADYZ, APE, ARK, ARL, DAX, DEJ, DHH, EY, JB, NM, QG, QH, TBG, TBQ, TCK, TDB, TDD, TDE, TDF, TFM, WV, WW, WX, YGA, YGL, YEU, YJF,
exactly 1 in spares ADF, ANZX, DEG, DZA, JF, MX, NT, QT, TAB, TBR, TBV, TDC, TDG, TDH, WL, YCA, ZKV

SMS Type in 1401 in Spares in 729
Y, Mod II only
1JMX 0 1 .
2JHX 1 0 .
2JMX 49 34 .
3JMX 51 46 .
3JWX 1 0 .
4JMX 54 53 .
6J-- 4 0 .
6JXD 28 0 .
AAF- 2 1 .
ABK . 5 Y
ACA- 1 0 .
ACX . . Y
ACW . . Y
ADB- 42 4 .
AEA- 4 7 .
AED- 9 3 .
AEN- 71 0 .
AFA . 5 Y
AIMX 0 1 .
AJT- 3 0 .
AK--

1
AKB- 2 0 .
AKC- 2 0 .
AM-- 2 1 .
APE-

6
APF-
3 3
APG-
1 2
APH
2 2
APN-


AQU- 39 0 .
AQV- 12 0 .
AQX- 7 0 .
AR--
7 7
ARK-

8
ARL-

8
AUC . 2 Y
AUD . 1 Y
AUS . . Y
AXQ- 1 0 .
AYWS

7
BJ--
6 8
BKVZ . . Y
BKWZ

Y
BKYZ

1
BMVB 1 0 .
BP . . Y
BQV- 1 0
CAC- 5 1 .
CD 0 4 11
CE 0 1 0
CEA- 8 1 .
CED- 12 0 .
CEE- 25 22 .
CEH- 22 8 .
CEJ- 1 0 .
CEK- 3 2 .
CEM- 31 11 .
CEYB

4
CFF 0 1 .
CFVU 0 13 .
CG-- 27 1 .
CGVV 38 8 .
CGVW 29 14 .
CGWU 1 0 .
CGWV 1 59 .
CGWW 49 25 .
CH-- 59 13 .
CHVH 1 0 .
CHVU 2 0 .
CHVV 37 7 .
CHVW 36 14 .
CHVY 1 0 .
CHWV 0 59 .
CHWW 56 1 .
CHYW 1 0 .
CJ-- 1 2 .
CJHF 1 0 .
CJVC 36 0 .
CJVV 1 0 .
CJVW 3 0 .
CJWF 111 79 .
CJWV 18 3 .
CJWW 1 0 .
CJYC 47 32 .
CKHF 1 0 .
CKMF 1 0 .
CKVC 14 2 .
CKVQ 1 0 .
CKVU 44 17 .
CKWF 76 34 .
CKWV 17 2 .
CKYA 1 0 .
CKYC 44 9 .
CL 0 1 .
CLV3 1 0
CLVC 1 0 .
CLVQ 56 16 .
CLVR 112 80 .
CLVS 12 0 .
CLVT 44 5 .
CLVW 1 0 .
CLWF 1 0 .
CM-- 2 2 .
CNWF 1 0 .
CNWT 20 14 .
CNWU 2 1 .
CPHT 1 0 .
CPNT 1 0 .
CPWT 20 16 .
CPWU 3 2 .
CQ-- 31 23 .
CQUG 1 0 .
CQVG 3 0 .
CQVW 0 2 .
CQYG 18 3 .
CQYZ 0 1 .
CQZ1 1 0 .
CQZB 1 0 .
CQZT 51 55 .
CQZV 59 43 .
CQZY 8 2 .
CR-- 23 12 .
CRUG 1 0 .
CRVG 5 0 .
CRWF 1 0 .
CRYG 10 4 .
CRZT 50 41 .
CRZV 51 24 .
CRZY 9 0 .
CV-- 15 0 .
CW-- 124 107 .
CWW 1 0 .
CWYG 1 0 .
CY-- 7 15 .
SMS Type in 1401 in Spares in 729
Y, Mod II only
DAB- 1 1 .
DAC-
2 1
DAX-

1
DAZ- 1 0 .
DBV- 1 0 .
DBZ- 3 0 .
DCK- 2 0 .
DDZ- 1 0 .
DEC- 1 0 .
DEF- 5 2 .
DEG- 2 0 .
DEJ- 1 0 .
DFJ- 10 1 .
DFQ- 4 1 .
DFR- 14 3 .
DFV- 1 0 .
DGJ- 1 0 .
DGP- 8 2 .
DGQ 7 1 .
DGS- 14 0 .
DGT- 20 1 .
DGU- 13 0 .
DGV- 16 2 .
DGW- 10 1 .
DGX- 20 1 .
DGY- 7 1 .
DGZ- 19 0 .
DH-- 1 0 .
DHA- 7 0 .
DHB- 8 1 .
DHC- 9 0 .
DHD- 4 1 .
DHE- 5 1 .
DHF- 15 0 .
DHG- 7 0 .
DHH- 4 0 .
DHJ- 4 0 .
DHK- 7 0 .
DKA- 8 0 .
DZA- 6 0 .
DZZA 1 0 .
EV-- 1 0 .
EY-- 2 0 .
FFVP 1 0 .
FP-- 4 1 .
FT-- 1 1 .
FW-- 12 5 .
GJ-- 13 2 .
GK-- 2 0 .
HN-- 8 0 .
HW--

.
JB-- 1 0 .
JF-- 3 0 .
JFVA 2 1 .
JFVN 12 1 .
JFVP 11 1 .
JG-- 8 1 .
JGVQ 1 0 .
JGVU 1 0 .
JGVV 7 1 .
JGVW 2 2 .
JGWW 20 2 .
JH-- 12 1 .
JHVB 5 0 .
JHVU 12 2 .
JHWV 7 1 .
JJ-- 1 1 .
JJVA 8 2 .
JJVN 7 3 .
JJVP 10 2 .
JLV? 1 0 .
JLV5 1 0 .
JLVB 85 42 .
JLVD 1 0 .
JLVG 1 0 .
JMV? 1 0 .
JMVB 18 30 .
JMVD 1 0 .
JMVG 1 0 .
JN-- 15 4 .
JNVB 1 0 .
JNVU 1 0 .
JZ-- 22 7 .
KA-- 29 21 .
KDB 0 1 .
LQZT 1 0 .
LZ--
7 7
MD--
2 8
MH--
1 4
MN--
2 .
MX--
11 37
NB-- 4 0 .
NC-- 7 1 .
NCNB 0 1
NGTF 10 2 .
NGXX 4 2 .
NJ 0 1 .
NM--

2
NT-- 1 0 .
NU-- 6 2 .
NW-- 8 0 .
PP-- 61 66 .
PQ-- 55 36 .
QC-- 4 3 .
QD-- 42 50 .
QG 0 1 .
QGVV 0 1
QH--

.
QHVV 0 1 .
QN--

.
QU 0 1 .
RK-- 1 1 .
RP--

2
TAB- 7 0 .
TAU-
11 1
TBG- 1 0 .
TBQ- 1 0 .
TBR- 1 0 .
TBS- 1 1 .
TCJ
5 Y
TCK- 2 0 .
TDB- 3 0 .
TDC- 1 0 .
TDD- 1 0 .
TDE- 1 0 .
TDF- 1 0 .
TDG- 1 0 .
TDH- 1 0 .
TDK- 1 0 .
TFM- 1 0 .
TG- 1 0 1
USED 3 0 .
VBV- 3 0 .
VBY- 4 0 .
VCC- 14 0 .
WB--
11 13
WL-- 6 1 .
WX-- 31 0 .
XQZT 1 0 .
XQZV 1 0 .
YAW-
2 2
YCA- 1 0 .
YCB- 1 0 .
YEW-

2
YHM-
1 1
YLA 0 1 .
ZJMX 1 2 .
ZKV- 1 0 .

- Jan 28, 2018 - e-mail from Jim Hunt, titled M1cards, identifying cards obtained from the 729 Mod 1 backplane by Marc Verdiell


Contents of the 729 model one Marc bought from [Holland]
7 rows of SMS cards, 91 cards total, 64 useful in 1401
Cards at left are used in 1401
tabbed cards are not

			ABK 5
			AEK
			AFA 5
APF 3
APG
APH 2
AR 7
			AUC 2
			AUD
			AY 7
BJ 6
			BK
CD 3
CE
DAC
LZ 7
MD 2
MH
MX 10
NM 2
TAU 4
			TCJ 5
WB 11
YAW 2
YHM
